Drive-in wedge anchor:
The internally threaded drive-in wedge anchor is intended primarily for fixing in concrete.
Inside the anchor there is a wedge which, driven in with a purpose-made tool, jams into the anchor’s internal negative cone; the anchor then opens out along its slot and, pressing against the wall of the hole with great force, is ready for assembly.
The anchor, made in sizes M6 – M24, is made of NONOX stainless (A2) or acid-resistant (A4) grade stainless steel. A drive-in tool can also be ordered for the anchor, which can be used for fixings to concrete ledges and concrete edges as well.
Ordering, technical description, dimensions: DRIVE-IN WEDGE ANCHOR
Ring anchor bolt
The ring anchor bolt, also known as the foundation bolt, guarantees a secure externally threaded fixing in concrete and stone, and is made in NONOX stainless and acid-resistant versions.
Under pull-out force the ring at the end of the bolt, fitted with claws and slots, stays behind and runs up onto the expansion cone formed at the end of the anchor bolt, where it opens out and so presses firmly against the wall of the hole. The harder we tighten the nut, the more tightly the anchor bolt grips in the hole.
The anchor bolt, available with nut and washer and made of NONOX stainless or acid-resistant stainless steel alloy, can also be ordered in a long-thread version.
Ordering, technical description, dimensions: RING ANCHOR BOLT
These products of ours can be collected from stock. Order from our online shop!
